Stainless steel or alloys container LY
- Stainless steel sampling container
- For sampling from 50 to 1000 ml
- Under multifunction valves
- All types of assembly
The LY container is the proven answer to the need for safe sampling of the most volatile and toxic chemicals, while preserving the integrity of the environment. Its robust design and ease of use make it the ideal tool for meeting these critical requirements. Designed for multi-function valves, it offers sampling capacities ranging from 50 ml to 1000 ml, covering a wide range of sampling needs. Available in a range of materials, including Hastelloy, it can be configured to meet specific requirements. A dual-chamber version has been developed for sampling sensitive liquids such as phosgene or HF. This design allows the sampled liquid to be mixed effectively with another liquid. The LY container is the benchmark for safe and effective sampling of the most delicate chemicals, offering a reliable and safe solution.
CONTAINER (LY)
With its unique, robust design, the LY simplifies sampling and analysis of highly hazardous products, avoiding direct contact with the product. This container promises unrivalled safety and integrity, thanks to its modularity in size and materials, as well as its adjustable sealings. Designed primarily for liquids, the LY effectively minimises any risk of exposure and prevents environmental contamination. It is suitable for liquid or gaseous products that expand.
Key Benefits:
- Optimal Safety: Ensures secure sampling and analysis
- Non-Contact Handling: Prevents direct product contact
- Robust Build: Designed to prevent dead zones
- Suitable for expanding products
- User-Friendly: Simple and intuitive usage
- Versatile Installation: Suitable for both horizontal and vertical lines
- Easy Maintenance: Dismantles effortlessly for cleaning
Modularity:
- Material Options: Choose from stainless steel or various alloys
- Flexible Sizes: Available in capacities ranging from 50 ml to 1000 ml
- Modular Design & sealing: Customizable to meet specific needs
Indicative drawing of a LY container under a horizontally mounted valve
CONTAINER WITH BELLOWS SEAL : LY-SO
Designed for applications requiring a high level of security, the container with bellows seal LY-SO excels in environments where rigorous leak management and sealing are paramount. Its robust structure facilitates safe sample collection and analysis, eliminating direct contact with the product. This device, guaranteeing safety and integrity, offers customization options in terms of size and materials. Particularly suited for the sampling of liquefied gases, gases under cryogenic conditions, and liquids in vapor phase, the LY-SO eliminates the risks of exposure and harmful emissions, thus protecting both the operator and the environment. It is suitable for liquid or gaseous products that expand.
Key benefits
- Optimal Sealing: Ensures total safety with leak control
- Sampling without product contact
- Robust Design: Free from dead zones
- Suitable for expanding products
- Simplified Use: Suitable for horizontal and vertical installation
- Easy cleaning and maintenance :can be dismantled
Modularity
- Available in stainless steel and various alloys
- Size Range: From 50 to 1000 ml
Indicative drawing of a container with bellows seal LY-SO under a horizontally mounted bellows valve
PFA LINED CONTAINER: LY-P-SO
Crafted from stainless cast iron and lined with either pure PFA or antistatic coating, the LY-P-SO container is purposefully engineered for the safe sampling of toxic and highly corrosive chemicals. Its robust design, free from dynamic joints, enhances its leak-proof capabilities and ensures maximum safety. With a capacity of 100 ml, this container significantly minimizes the risks of exposure and dissemination of hazardous substances, providing exceptional protection for both users and the environment. It is suitable for liquid or gaseous products that expand.
Key Benefits:
- Acid Resistance: Unaffected by acidic environments
- Suitable for expanding products
- Non-Contact Sampling: Ensures safe handling
- Robust Design: Free from dead zones
- User-Friendly: Easy to use and disassemble
- Versatile Mounting: Suitable for both horizontal and vertical installations
Modularity:
- Material Options: Available in pure PFA and antistatic PFA
Indicative drawing of a PFA lined container: LY-SO-P under a lined valve mounted horizontally
DOUBLE CHAMBER CONTAINER (LY/2)
For handling certain lethal products, specific neutralization procedures are essential to ensure safety. The LY/2 container, with its unique dual-chamber design, facilitates these critical operations. This innovative design allows efficient mixing of sampled liquids with neutralizing agents. Available in various materials, the LY/2 features a main chamber and a neutralization chamber, offering exceptional modularity in both material and size configurations.
Key benefits
- On-Container product neutralization: Ensures safe handling and removal
- Non-Contact Sampling: Prevents direct exposure
- Robust Design: Eliminates dead zones
- User-Friendly: Easy to use and disassemble
- Versatile Installation: Suitable for both horizontal and vertical lines
Modularity
- Material Options: Available in various materials
- Custom Sealing: Tailored to product specifications
- Adjustable Chambers: Main and neutralization chambers can be tailored in size
Indicative drawing of an LY-2 double-chamber container under a horizontally mounted valve
ADDITIONAL ACCESSORIES
Standard product range
BIAR SA offers inline sampling valves that can be adapted to your sampling and production constraints
